TMR 0510 | TRACO POWER
DC converter, 4.5-9 VDC, 1.7 W, 1 output, 3.3 VDC, 76 % efficiency, TMR 0510
Unit Price (€ / pc.)
15.9698 € *
Available: 0 pcs.
Next delivery: 10 pcs. on 2025-06-06
Leadtime: 20 Weeks **
Total Price:
15.97 € *
Price list
Quantity
Price per unit*
1 pcs.
15.9698 €
10 pcs.
14.3871 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TMR 0510
The TMR-2 series is a family of isolated 2W dc-dc converter modules with regulated output, featuring wide 2:1 input voltage ranges. The product comes in a compact SIP-8 plastic package with small footprint occupying only 2.0 cm² (0.3 square in.) of board space. An excellent efficiency allows –40° to +85°C operation temperatures. Further features include remote On/Off control and continuous short circuit protection. The ultra-compact dimensions of these converters make them an ideal solution for many space critical applications in communication equipment, instrumentation and industrial electronics.
Technical specifications
| Anzahl der Ausgänge | 1 | |
| Ausgangsspannungsbereich | 3,3 VDC | |
| Ausgangsstrom | 500 mA | |
| Bauform | SIP8 | |
| Breite | 9.3 mm | |
| Eingangsspannungsbereich | 4,5-9 VDC | |
| Höhe | 11.2 mm | |
| Isolationsspannung | 1.5 kV | |
| Länge | 21.8 mm | |
| Leistung | 1.7 W | |
| Wirkungsgrad | 76 % |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
