TMR 1-1213SM | TRACO POWER
DC/DC converter, 9-18 VDC, 1 W, 1 output, 15 VDC, 82 % efficiency, TMR 1-1213SM
Unit Price (€ / pc.)
14.4942 € *
Available: 6 pcs.
Leadtime: 14 Weeks **
Total Price:
14.49 € *
Price list
Quantity
Price per unit*
1 pcs.
14.4942 €
10 pcs.
13.0543 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TMR 1-1213SM
The TMR 1SM serie relatives to the familiy of isolated 1 W dc-dc converter modules with regulated output, featuring wide 2:1 input voltage ranges. These products come in a compact SMD package with small footprint. An excellent efficiency allows –40°C to +85°C operation temperature. Further features include remote On/Off control (SMD-Version) and continuous short circuit protection. The compact dimensions and cost optimised design make this converters an ideal solution for applications in communication equipment, instrumentation and industrial electronics.
Technical specifications
| Anzahl der Ausgänge | 1 | |
| Ausgangsspannungsbereich | 15 VDC | |
| Ausgangsstrom | 67 mA | |
| Bauform | SMD | |
| Breite | 13.7 mm | |
| Eingangsspannungsbereich | 9-18 VDC | |
| Höhe | 8.7 mm | |
| Isolationsspannung | 1.5 kV | |
| Länge | 18.9 mm | |
| Leistung | 1 W | |
| Wirkungsgrad | 82 % |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
