FRS 5 X 8 OHM | VISATON
Broadband speaker, 8 Ω, 86 dB, 120 Hz to 20 kHz, black, FRS 5 X 8 OHM
Order No.: 38M588
EAN: 4007540022352
MPN:
FRS 5 X 8 OHM
LAUTSPRECHER FRS 5 X 8 Ohm
Unit Price (€ / pc.)
12.5426 € *
Available: 0 pcs.
Leadtime: 1 Week **
Fullrange speakers, type Visaton FRS 5 X.
With black basket, suitable for use a s fullrange or midrange speaker, as well as for ELA systems with 100-V technology; Rated/peak power: 5.0/8.0 W. Impedance: 8.0 ohm. Mean sound pressure level: 86 dB. Frequency response: 120 to 20000 Hz. Resonant frequency: 190 Hz. Operating temperatures: –25 to +70 °C. Dimensions: 68 x 33.5 mm. Weight: 140 g.
Type: 2235, fullrange speaker
Technical specifications
| Version | broadband speaker | |
| Installation diameter | 45 mm | |
| Colour | black | |
| Impedance | 8 Ω | |
| Max. transmission range | 20 kHz | |
| min. transmission range | 120 Hz | |
| Resonance frequency | 190 Hz | |
| Sound pressure level | 86 db |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85182900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
