GRC00PB3311CTNL | Vishay
Electrolytic capacitor, 330 µF, 16 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm, GRC00PB3311CTNL
Unit Price (€ / pc.)
0.0393 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Electrolytic capacitor in aluminum can, type Vishay GRC.
For vertical mounting
Rated voltage 16 VDC.
Technical specifications
| Version | polar | |
| Design | radial | |
| diameter | 8 mm | |
| Capacity | 330 µF | |
| Length | 11.5 mm | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -40 °C | |
| Rated voltage (DC) | 16 V | |
| Grid | 3.5 mm | |
| Ripple current | 270 mA | |
| Tolerance | ±20 % |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85322200 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
