MAL202138478E3 | Vishay
Electrolytic capacitor, 4.7 µF, 63 V (DC), -10/+30 %, axial, Ø 4.5 mm, MAL202138478E3
Unit Price (€ / pc.)
5.3431 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
5.34 € *
Price list
Quantity
Price per unit*
1 pcs.
5.3431 €
10 pcs.
2.7132 €
100 pcs.
1.8921 €
500 pcs.
1.6422 €
1000 pcs.
1.4875 €
*incl. VAT plus shipping costs
**Subject to prior sale
Electrolytic capacitor, insulated aluminum can, type Vishay/BComponents MAL 20.
Axial
Rated voltage 63 VDC.
Technical specifications
| Version | polar | |
| Design | axial | |
| diameter | 4.5 mm | |
| ESR (Equivalent Series Resistance) | 31 Ω | |
| Capacity | 4.7 µF | |
| Length | 11 mm | |
| max. operating temperature | 85 °C | |
| min. operating temperature | -40 °C | |
| Rated voltage (DC) | 63 V | |
| Ripple current | 31 mA | |
| Tolerance | -10/+30 % |
Download
Logistics
| Country of origin | AT |
| Customs tariff number | 85322200 |
| Original Packaging | Ammopack with 1,000 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
