RH00510K00FE05 | Vishay
Wirewound resistor, 10 kΩ, 7.5 W, ±1 %, RH00510K00FE05
Unit Price (€ / pc.)
3.7366 € *
Available: 0 pcs.
Leadtime: 12 Weeks **
Precision wire-wound power resistors, 7.5/5.0 W, tolerance 1.0 %, type Vishay/Dale RH-5.
For chassis mounting, hermetically sealed aluminum package, certified to MiL-R-18546 RE-60 G
Technical specifications
| ohmic resistance | 10 kΩ | |
| Version | Drahtwiderstand | |
| Design | Chassis | |
| Width | 12.45 mm | |
| Height | 8.13 mm | |
| Length | 15.24 mm | |
| Power | 7.5 W | |
| max. operating temperature | 250 °C | |
| min. operating temperature | -55 °C | |
| Assembly | Chassismontage | |
| Tolerance | ±1 % | |
| Temperature coefficient | ±20 ppm/K |
Download
Logistics
| Country of origin | US |
| Customs tariff number | 85332100 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
