BZX85-C22 | Vishay

Name: Silicon planar zener diode, 22 V, 1.3 W, DO-41, BZX85-C22
Brand: Vishay
SKU: 22S9838
Price: 0.12 EUR
Availability: OutOfStock

Silicon planar zener diode, 22 V, 1.3 W, DO-41, BZX85-C22

Order No.: 22S9838

EAN: 4099879081896

MPN:

BZX85-C22

Series: BZX85

Image may differ

Key Specification:

Number of diodes 1

Version Silicon planar zener diode

Assembly THT

Enclosure DO-41

Zener voltage 22 V

Show 21 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.1249 € *

Available: 0 pcs.

Leadtime: On Request **

Add to Cart

Total Price:

0.12 € *

Price list

Quantity

Price per unit*

5 pcs.

0.1249 €

50 pcs.

0.1071 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Zener diodes, 1.3 W, series BZX85.

Power losses: 1.3 W. Package: DO41.

Technical attributes (type, Zener voltage, manufacturer): BZX85/C22, 22 V

Download

Technical Data Sheet - EN Technical Data Sheet

Declaration of Conformity - EN Declaration of Conformity

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	CN
Customs tariff number	85411000
Original Packaging	Reel with 5,000 pieces

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes

1 item in 21 variations
