753-425 | WAGO

Input module, Inputs: 2, (W x H x D) 12 x 100 x 698 mm, 753-425

Order No.: 44P5667
EAN: 4045454834715
MPN:
753-425
Series: 753
753-425 WAGO Digital modules Image 1
753-425 WAGO Digital modules Image 2
753-425 WAGO Digital modules Image 3
Image may differ
Unit Price (€ / pc.)
83.1215 € *
Available: 0 pcs.
Leadtime: 5 Weeks **
Total Price:
83.12 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
83.1215 €

Digital input, 753-425, WAGO

2-channel digital input, NAMUR.

Features

  • This digital input module receives control signals from NAMUR proximity sensors (per DIN EN 60947-5-6) from the field side
  • Each channel of the sensors is supplied with a short-circuit-protected voltage of 8.2 V. A short circuit or a line break is indicated in the process image (1 bit) and via the red LED
  • Field and system levels are electrically isolated
Technical specifications
Anzahl der digitalen Eingänge 2
Ausführung Eingangsmodul
Breite 12 mm
Höhe 100 mm
Montage DIN-Schiene
Tiefe 698 mm
Logistics
Ursprungsland DE
Zolltarifnummer 85389099
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei No
Substanz Beschreibung Bortrioxid, Bleimonoxid (Bleioxid), Blei
