811-321 | WAGO
2-wire fuse terminal, 2 pole, 2.5-16 mm², 690 V, 32 A, 811-321
Unit Price (€ / pc.)
45.2676 € *
Available: 0 pcs.
Leadtime: 1 Week **
Total Price:
45.27 € *
Price list
Quantity
Price per unit*
1 pcs.
45.2676 €
5 pcs.
43.0066 €
10 pcs.
39.9959 €
25 pcs.
37.1994 €
*incl. VAT plus shipping costs
**Subject to prior sale
2-conductor fuse holder, 811-321, WAGO
2-conductor fuse holder, for cylindrical fuses 10 x 38 mm, 13/32" x 11/2", 2-pole, with blown fuse indication, 600 VAC/VDC, for DIN-rail 35 x 15 and 35 x 7.5, 16 mm², CAGE CLAMP, 16,00 mm², light gray
Technical specifications
| Connection | tension clamp connection | |
| Number of terminals | 4 | |
| Version | Fuse terminal block | |
| AWG cross-section | AWG 14 to 6 | |
| Rated Voltage | 690 V | |
| Width | 35 mm | |
| Colour | light gray | |
| Height | 105 mm | |
| Cable cross-section | 2.5-16 mm² | |
| Rated current | 32 A | |
| Pin number | 2 pole | |
| Degree of soiling | 3 |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85369095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
