2091-1377/200-000 | WAGO

Socket header, 7 pole, pitch 3.5 mm, angled, light gray, 2091-1377/200-000

Order No.: 44P7344
EAN: 4055143472234
MPN:
2091-1377/200-000
Series: 2091
2091-1377/200-000 WAGO PCB Connection Systems Image 1
2091-1377/200-000 WAGO PCB Connection Systems Image 2
Image may differ
Unit Price (€ / pc.)
5.1289 € *
Available: 0 pcs.
Leadtime: 3 Weeks **
Total Price:
5.13 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
5.1289 €

THR female connector, 2091-1377/200-000, WAGO

1-conductor THR female connector angled, push-button, Push-in cage clamp, 1.5 mm², Pin spacing 3.5 mm, 7-pole, 1.0 mm Ø solder pin, 1.50 mm², light gray.

Features

  • Universal connection for all conductor types
  • Easy-to-use design does not require special tools
  • Ability to wire while mated or unmated
  • Integrated test ports for testing parallel to conductor entry
Technical specifications
Anschluss Push-in
Anzahl der Reihen 1
Ausführung Buchsenleiste
Farbe lichtgrau
Kontaktart Buchse
Kontaktoberfläche verzinnt
Nennspannung 160 V
Nennstrom 10 A
Orientierung abgewinkelt
Polzahl 7-polig
Rastermaß 3.5 mm
Verriegelung Nein
Logistics
Ursprungsland DE
Zolltarifnummer 85366990
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei No
