769-608/001-000 | WAGO
Pin header, 8 pole, pitch 5 mm, straight, gray, 769-608/001-000
Unit Price (€ / pc.)
7.2233 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
7.22 € *
Price list
Quantity
Price per unit*
1 pcs.
7.2233 €
10 pcs.
6.6402 €
50 pcs.
6.0452 €
100 pcs.
5.4383 €
*incl. VAT plus shipping costs
**Subject to prior sale
1-Conductor male connector, 769-608/001-000, Wago
Male connector with CAGE CLAMP connection and snap-in lugs for sheet thickness 0.6 - 1.2 mm fixing holes Ø 3.5 mm with mounting adapter 209-137 also on TS 35 pitch 5 mm / 0.197 in 8-pole gray
Technical specifications
| Connection | spring-cage connection | |
| Version | pin header | |
| Additional parts | equipped | |
| Colour | gray | |
| Contact type | pin | |
| Rated voltage | 500 V | |
| Rated current | 32 A | |
| Orientation | straight | |
| Pin number | 8 pole | |
| Grid | 5 mm |
Download
Logistics
| Country of origin | PL |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
