744-392/000-007 | WAGO
PCB terminal, 2 pole, pitch 3.5 mm, AWG 20-16, 3 A, push-in, gray, 744-392/000-007
Unit Price (€ / pc.)
0.6069 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
PCB terminal block, 744-392/000-007, WAGO
PCB terminal block, 1.5 mm², Pin spacing 3.5 mm, 2-pole, PUSH WIRE, 1.5 mm², gray.
Features
- PCB terminal blocks with PUSH WIRE connection
- Push-in termination of solid conductors – low insertion forces
- Conductor removal via disconnection tool or by twist & pull
Technical specifications
| Anschluss | Push-in | |
| AWG-Leiterquerschnitt | AWG 20-16 | |
| Breite | 7.9 mm | |
| Farbe | grau | |
| Höhe | 10.1 mm | |
| Leiterquerschnitt | 0,5-1,5 mm² | |
| Nennspannung | 320 V | |
| Nennstrom | 3 A | |
| Polzahl | 2-polig | |
| Rastermaß | 3.5 mm | |
| Tiefe | 12.5 mm |
Download
Logistics
| Ursprungsland | CH |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
