771-5001/225-000 | WAGO

Y cable, 0.5 m, plug/plug, 3-/5 pole straight to socket, 5 pole straight, 1.5 mm², 2.5 mm², 771-5001/225-000

Order No.: 45P6305
EAN: 4055143848404
MPN:
771-5001/225-000
Series: WINSTA MIDI
771-5001/225-000 WAGO Pre-assembled Connector Systems Image 1
771-5001/225-000 WAGO Pre-assembled Connector Systems Image 2
Image may differ
Unit Price (€ / pc.)
35.2954 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
35.30 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
35.2954 €

Y-cable, 771-5001/225-000, WAGO

The WINSTA MIDI Connecting line is useful when specifications repeat or are distributed on a specific grid, for example for installing grid lighting or flush-mount lighting. The mechanical coding and color coding of the pluggable installation connector ensure error-free installation of the individual components - including protection against mismating. The pluggable installation connector is protected against ingress by solid objects in accordance with protection type IP20. With its Push-in Cage Clamp spring pressure connection technology, it ensures time-saving, error-free installation and offers flexibility and customization for meeting an enormous variety of installation requirements.

The Connecting line is provided with a MIDI plug, a MIDI plug and a MIDI socket. WINSTA is the pluggable connection system that is optimally tailored to the strict requirements of electrical installation. It offers fast, secure and, above all, error-free installation of components and cables.

Features

  • Pluggable installation connector with protection against mismating
  • With B coding for controllers, for example lighting fixtures and sun blinds
  • Ready to install and use immediately
  • Quick replacement of defective units during ongoing operation
Technical specifications
Anschluss (1) Stecker/Stecker, 3-/5-polig
Anschluss (2) Buchse, 5-polig
Ausführung Y-Kabel
Bauform Anschluss 1 gerade
Bauform Anschluss 2 gerade
Kabellänge 0.5 m
Kodierung B
Leiterquerschnitt 1,5 mm², 2,5 mm²
Logistics
Ursprungsland DE
Zolltarifnummer 85444290
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei No
