774-9293/217-401 | WAGO
Connection line, 4 m, plug straight to open end, 2.5 mm², 774-9293/217-401
Unit Price (€ / pc.)
32.5941 € *
Available: 0 pcs.
Leadtime: On Request **
Connection cable, 774-9293/217-401, WAGO
This Connecting line is the pluggable solution for your use in control cabinets, on PCBs or for lighting connections. For greater protection in electrical installations, the pluggable installation connector is equipped with mechanical protection against mismating. The pluggable installation connector is protected in accordance with protection type IP20.
This product has a current rating of 20 A - therefore it is also suitable for powerful loads. This product complies with the requirements of fire class B2. In the production of this Connecting line, halogens were deliberately omitted. This is an important contribution to environmental protection.
Features
- For any mains application
- Custom-engineered solutions
- Convenient installation and commissioning
Technical specifications
| Connection (1) | plug | |
| Connection (2) | open end | |
| Version | connection line | |
| Connection 1 design | straight | |
| Cable length | 4 m | |
| Cable cross-section | 2.5 mm² |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85444290 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
