774-9993/207-802 | WAGO
Connection line, 8 m, plug straight to open end, 2.5 mm², 774-9993/207-802
Unit Price (€ / pc.)
27.3343 € *
Available: 0 pcs.
Leadtime: On Request **
Connection cable, 774-9993/207-802, WAGO
Connecting line with coding options to reduce installation errors, allowing fast, secure wiring of all components. The pluggable installation connector is protected against ingress by solid objects in accordance with protection type IP20.
This pluggable installation connector can be employed for a current load of up to 20 A. Thus, it can also be used for high power loads. It fits into drill holes and conduits with diameters up to 20 mm. This product meets all the relevant fire protection requirements of fire class E; therefore it can be used in areas where fire safety is relevant.
Features
- Suitable for any application
- Guarantees safe use
- Convenient installation and commissioning
Technical specifications
| Connection (1) | plug | |
| Connection (2) | open end | |
| Version | connection line | |
| Connection 1 design | straight | |
| Cable length | 8 m | |
| Cable cross-section | 2.5 mm² |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85444290 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
