769-217 | WAGO
2-wire/2-pin PE basic terminal, spring-clamp connection, 0.08-4.0 mm², 1 pole, 32 A, yellow/green, 769-217
Unit Price (€ / pc.)
3.1773 € *
Available: 0 pcs.
Leadtime: 3 Weeks **
Total Price:
3.18 € *
Price list
Quantity
Price per unit*
1 pcs.
3.1773 €
10 pcs.
2.9155 €
50 pcs.
2.6537 €
100 pcs.
2.3919 €
*incl. VAT plus shipping costs
**Subject to prior sale
2-Conductor/2-pin ground carrier terminal block, 769-217, Wago
2-conductor/2-pin PE basic terminal block according to EN 60715 green-yellow
Technical specifications
| Anschluss | Federklemmanschluss | |
| Anzahl der Klemmstellen | 2 | |
| Ausführung | 2-Leiter/2-Pin-PE-Basisklemme | |
| AWG-Leiterquerschnitt | AWG 28 bis 12 | |
| Bemessungsspannung | 500 V | |
| Breite | 5 mm | |
| Farbe | gelb/grün | |
| Höhe | 87.5 mm | |
| Länge | 28.5 mm | |
| Leiterquerschnitt | 0,08-4,0 mm² | |
| Nennstrom | 32 A | |
| Polzahl | 1-polig | |
| Verschmutzungsgrad | 3 |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
