243-212 | WAGO
Socket terminal, 2 pole, 5.0-6.0 mm², clamping points: 8, light gray/yellow, clamp connection, 6 A, 243-212
Unit Price (€ / pc.)
0.7616 € *
Available: 48 pcs.
Leadtime: 4 Weeks **
Total Price:
0.76 € *
Price list
Quantity
Price per unit*
1 pcs.
0.7616 €
10 pcs.
0.7021 €
50 pcs.
0.6426 €
100 pcs.
0.5831 €
*incl. VAT plus shipping costs
**Subject to prior sale
Connector, 243-212, WAGO
4-conductor modular PCB connector, PUSH WIRE, 0.8 mm Ø, pin spacing 5.75 mm, 2-pole, for individual solder pins, for KNX, light gray/yellow.
Features
- Compact design
- Push-in termination of solid conductors
- Four-conductor entries allow devices to be replaced without disrupting the KNX/EIB bus connection
Technical specifications
| Connection | clamp connection | |
| Number of terminals | 8 | |
| Version | socket terminal | |
| AWG cross-section | AWG 22-20 | |
| Colour | light gray/yellow | |
| Cable cross-section | 5.0-6.0 mm² | |
| Rated current | 6 A | |
| Pin number | 2 pole |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
