773-108 | WAGO
Cable connector, 5 pole, 0.75-2.5 mm², clamping points: 8, dark gray, push-in wire connection, 24 A, 773-108
Unit Price (€ / pc.)
0.5236 € *
Available: 0 pcs.
Leadtime: 10 Weeks **
Total Price:
0.52 € *
Price list
Quantity
Price per unit*
1 pcs.
0.5236 €
10 pcs.
0.4760 €
50 pcs.
0.4284 €
100 pcs.
0.3927 €
*incl. VAT plus shipping costs
**Subject to prior sale
Connector, 773-108, WAGO
PUSH WIRE connector for junction boxes, for solid and stranded conductors, maximum 2.5 mm², 8-conductor, transparent housing, dark gray cover, surrounding air temperature: maximum 60 °C, 2,50 mm², multicoloured.
Technical specifications
| Version | Verbindungsklemme | |
| Pin number | 5-polig | |
| Cable cross-section | 0,75-2,5 mm² | |
| Number of terminals | 8 | |
| Colour | dunkelgrau | |
| Connection | Push-in-Drahtanschluss | |
| Rated current | 24 A | |
| AWG cross-section | AWG 18-12 |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
