289-553 | WAGO

Name: Transfer module, 37 pole, 2 A, 125 V, 289-553
Brand: WAGO
SKU: 43P1836
Price: 105.27 EUR
Availability: OutOfStock

Transfer module, 37 pole, 2 A, 125 V, 289-553

Order No.: 43P1836

EAN: 4045454498559

MPN:

289-553

Series: 289

289-553 WAGO Transfer Modules for Mounting Rail Image 2

Image may differ

Key Specification:

Version transfer module

Pin number 37 pole

Rated current 2 A

Rated voltage 125 V

Length 85 mm

Show 35 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

105.2674 € *

Available: 0 pcs.

Leadtime: On Request **

Add to Cart

Total Price:

105.27 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Interface module, 289-553, WAGO

Interface module with solder pin, Female connector, 37-pole, for mating connectors with IDC, Vertical mounting, PCB terminal blocks, Double-row in mounting carrier, 2.50 mm².

Technical specifications

Download

Technical Data Sheet - EN Technical Data Sheet

Declaration of Conformity - EN Declaration of Conformity

Technical Data Sheet - DE Technical Data Sheet

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	DE
Customs tariff number	85369010

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes

1 item in 35 variations
