35870910 | Weco
Flat plug connector, 10 pole, 2.8 x 0.8 mm, L 48.5 mm, insulated, red, 1.0 mm², AWG 16, 35870910
Unit Price (€ / pc.)
1.8921 € *
Available: 81 pcs.
Leadtime: 20 Weeks **
Total Price:
1.89 € *
Price list
Quantity
Price per unit*
1 pcs.
1.8921 €
25 pcs.
1.6184 €
100 pcs.
1.4994 €
250 pcs.
1.4280 €
1000 pcs.
1.3090 €
*incl. VAT plus shipping costs
**Subject to prior sale
Flat plug connector, 900-SH-5/10, Weco
The tab connector 900-SH-5/10 with double solder termination and a pitch of 5 mm is designed for 2 x 2.8 mm tab connector receptacles. Depending on the respective application it allows to plug in bare, partially or fully insulated tab receptacles according to DIN 46247. Two non-insulated 2.8 mm tab receptacles can be plugged in parallel.
Technical specifications
| Connection | Lötanschluss | |
| Version | Flachsteckerleiste, 10-polig | |
| AWG cross-section | AWG 16 | |
| Insulation colour | rot | |
| Isolated | Yes | |
| Length | 48.5 mm | |
| Cable cross-section | 1,0 mm² | |
| Material | Messing, verzinnt | |
| Nominal size according to DIN | DIN 46247 | |
| Plug width x plug thickness | 2,8 x 0,8 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
