10801405 | Weco
PCB terminal, 5 pole, pitch 5 mm, AWG 26-14, 16 A, screw connection, gray, 10801405
Unit Price (€ / pc.)
2.1420 € *
Available: 1 pcs.
Leadtime: 20 Weeks **
Total Price:
2.14 € *
Price list
Quantity
Price per unit*
1 pcs.
2.1420 €
25 pcs.
1.8088 €
100 pcs.
1.6660 €
250 pcs.
1.5946 €
1000 pcs.
1.4518 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB screw connector, type Weco
With solder pins for PCB mounting and screw terminals with lift system. Dovetail interlocking feature for multi-pole assembly and different design.
Strip length: 25 mm
Shell: tough polyamide, self-extinguishing
PCB hole diameter: 1.2 mm
Rated cross-section: 1.5 mm²
Technical specifications
| Anschluss | Schraubanschluss | |
| AWG-Leiterquerschnitt | AWG 26-14 | |
| Farbe | grau | |
| Höhe | 13.5 mm | |
| Kontaktabstand | RM 5/5,08 | |
| Leiterquerschnitt | 0,14-2,5 mm² | |
| Nennspannung | 300 V | |
| Nennstrom | 16 A | |
| Polzahl | 5-polig | |
| Rastermaß | 5 mm | |
| Tiefe | 10 mm |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
