12486871 | WEG
Auxiliary contactor, 4 pole, 10 A, 1 Form A (N/O) + 3 Form B (N/C), coil 24 VDC, screw connection, 12486871
Nicht mehr im Sortiment
Unit Price (€ / pc.)
18.2665 € *
Available: 5 pcs.
Leadtime: On Request **
Auxiliary Contactor, 12486871, Weg
Auxiliary Contactor CWCA0 1NO/3NC, 24V DC. Developed for different applications on control circuits. It can be directly mounted on DIN rail, or tightened with screws, and offer compact size and a full line of accessories.
Features
- Protected against foreign bodies and touch
- High reliability of the contacts
- Low-consumption DC coils
Technical specifications
| Anschluss | Schraubanschluss | |
| Ausführung | Hilfsschütz | |
| Bemessungsspannung (AC) | 690 V | |
| Montage | DIN-Schiene/Schraube | |
| Nennstrom | 10 A | |
| Polzahl | 4-polig | |
| Schaltfunktion | 1 Schließer + 3 Öffner | |
| Schutzart (IP) | IP20 | |
| Steuerspannung | 24 VDC |
Download
Logistics
| Ursprungsland | BR |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | not_specified |
