1137810000 | Weidmüller
Relay coupler 2 Form C (NO/NC), 1440 Ω, 8 A, 24 V (DC), 1137810000
Order No.: 50P6739
EAN: 4032248919666
MPN:
1137810000
RCIKIT 24VDC 2CO LD MC
Series: RIDERSERIES RCI
Unit Price (€ / pc.)
17.9333 € *
Available: 0 pcs.
Leadtime: 2 Weeks **
Relay coupler, 1137810000, Weidmüller
Relay coupler, with metal retaining clip, 24 VDC, green LED, Free-wheeling diode, 2 changeover contacts (AgNi 90/10), 250 VAC, 8 A, Screw connection, Relay coupler as mounted assembly consisting of plug-in Relay and plug-in base. Control and load circuit are galvanically isolated.
Technical specifications
| Anschluss | Schraubanschluss | |
| Ausführung | Relaiskoppler | |
| Kontaktart | 2 Wechsler | |
| Kontaktmaterial | AgNi | |
| Nennspannung (DC) | 24 V | |
| Nennstrom | 8 A | |
| Schutzart (IP) | IP20 | |
| Spulenwiderstand | 1440 Ω | |
| Statusanzeige | LED, grün |
Download
Logistics
| Ursprungsland | RO |
| Zolltarifnummer | 85364900 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
