7940006158 | Weidmüller

Relay coupler 1 Form C (NO/NC), 1440 Ω, 16 A, 24 V (DC), 7940006158

Order No.: 53P4091
EAN: 4032248475001
MPN:
7940006158
RCLKIT 24VDC 1CO LED GN
Series: RIDERSERIES RCL
Weidmüller
7940006158 Weidmüller Coupling Relays
Image may differ
Unit Price (€ / pc.)
16.7314 € *
Available: 0 pcs.
Leadtime: 2 Weeks **
Total Price:
16.73 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
16.7314 €

Relay coupler, 7940006158, Weidmüller

Relay coupler, 24 VDC, LED green, Free-wheeling diode, 1 changeover contact (AgNi 90/10), 250 VAC, 16 A, Screw connection, Relay coupler as mounted assembly consisting of plug-in relay and plug-in socket. Control and load circuit are galvanically isolated.

Technical specifications
Connection screw connection
Version Relay coupler
Contact type 1 Form C (NO/NC)
Contact material AgNi
Rated voltage (DC) 24 V
Rated current 16 A
Degree of protection (IP) IP20
Coil resistance 1440 Ω
Status display LED, green
Logistics
Country of origin DE
Customs tariff number 85364900
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free No
Substance description lead, 4,4'-isopropylidenediphenol
