1582370000 | Weidmüller
Pin contact, 2.5 mm², AWG 14-12, crimp connection, gold-plated, 1582370000
Unit Price (€ / pc.)
1.2138 € *
Available: 0 pcs.
Leadtime: 13 Weeks **
Pin contact, 1582370000, Weidmüller
The 1582370000 is a pin contact standard. This product enables custom adaptations to the specific requirements of your applications.
Features
- Safe centring of the contacts using the three-segment pin tips
- High contact reliability using four defined contact points
- Locking clasp in the cantilever spring for a secure mount of the contacts in the housing
- Pin contacts with two lengths to implement leading-pin contacts
Technical specifications
| Ausführung | Stiftkontakt | |
| AWG-Leiterquerschnitt | AWG 14-12 | |
| Isolationsdurchmesser | 2,8-4,2 mm | |
| Kontaktanschluss | Crimpanschluss | |
| Kontaktmaterial | Messing | |
| Kontaktoberfläche | vergoldet | |
| Leiterquerschnitt | 2,5 mm² |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85366990 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
