1358650000 | Weidmüller
Pin header, 8 pole, pitch 3.5 mm, straight, black, 1358650000
Order No.: 51P2350
EAN: 4050118161380
MPN:
1358650000
S2C-SMT 3.50/08/180LF 1.5SN BK RL
Unit Price (€ / pc.)
2.8441 € *
Available: 0 pcs.
Available in 6 Days: 350 pcs.
Leadtime: 8 Weeks **
Male connector, 1358650000, Weidmüller
PCB connector, solder flange, THT/THR solder termination, 3.50 mm, no. of poles: 8, 180°, 1.5 mm, tin plated, black, tape (Ø 330 mm); Rs = 10
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Connection | Leiterplattenanschluss | |
| Number of rows | 2 | |
| Version | Stiftleiste | |
| Additional parts | bestückt | |
| Colour | schwarz | |
| Contact type | Stift | |
| contact surface | verzinnt | |
| Rated voltage | 200 V | |
| Rated current | 13.4 A | |
| Orientation | gerade | |
| Pin number | 8-polig | |
| Grid | 3.5 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
