1728980000 | Weidmüller
Pin header, 12 pole, pitch 3.5 mm, straight, black, 1728980000
Order No.: 51P9935
EAN: 4032248040414
MPN:
1728980000
S2L 3.50/12/180G 3.5SN BK BX
Unit Price (€ / pc.)
2.6299 € *
Available: 0 pcs.
Available in 6 Days: 390 pcs.
Leadtime: On Request **
Male connector, 1728980000, Weidmüller
Printed circuit board connector, lateral closed, THT solder termination, 3.50 mm, no. of poles: 12, 180°, 3.5 mm, tinned, black, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Connection | Leiterplattenanschluss | |
| Number of rows | 2 | |
| Version | Stiftleiste | |
| Additional parts | bestückt | |
| Colour | schwarz | |
| Contact type | Stift | |
| contact surface | verzinnt | |
| Rated voltage | 250 V | |
| Rated current | 10 A | |
| Orientation | gerade | |
| Pin number | 12-polig | |
| Grid | 3.5 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
