1842100000 | Weidmüller
Pin header, 4 pole, pitch 3.5 mm, angled, black, 1842100000
Order No.: 52P3064
EAN: 4032248353453
MPN:
1842100000
SL-SMT 3.50/04/90F 3.2SN BK BX
Unit Price (€ / pc.)
2.1063 € *
Available: 0 pcs.
Leadtime: 7 Weeks **
Total Price:
2.11 € *
Price list
Quantity
Price per unit*
1 pcs.
2.1063 €
10 pcs.
1.9635 €
50 pcs.
1.7493 €
*incl. VAT plus shipping costs
**Subject to prior sale
Male connector, 1842100000, Weidmüller
Printed Circuit Board Connector, flange, THT/THR solder termination, 3.50 mm, no. of poles: 4, 90°, 3.2 mm, tin plated, black, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Connection | Leiterplattenanschluss | |
| Number of rows | 1 | |
| Version | Stiftleiste | |
| Additional parts | bestückt | |
| Colour | schwarz | |
| Contact type | Stift | |
| contact surface | verzinnt | |
| Rated voltage | 320 V | |
| Rated current | 15 A | |
| Orientation | abgewinkelt | |
| Pin number | 4-polig | |
| Grid | 3.5 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
