1948910000 | Weidmüller
Pin header, 14 pole, pitch 5.08 mm, angled, orange, 1948910000
Order No.: 52P7556
EAN: 4032248626366
MPN:
1948910000
BLZP 5.08HC/14/270 SN OR BX
As a private customer, you can buy this item as soon as we have it back in stock.
Male connector, 1948910000, Weidmüller
Printed circuit board connector, male header, closed side, 5.08 mm, no. of poles: 14, tinned, orange, Box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Connection | screw connection | |
| Number of rows | 1 | |
| Version | socket header | |
| Additional parts | equipped | |
| Colour | orange | |
| Contact type | socket | |
| contact surface | tin-plated | |
| Rated voltage | 400 V | |
| Rated current | 23 A | |
| Orientation | angled | |
| Pin number | 14 pole | |
| Grid | 5.08 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
