2439680000 | Weidmüller
Socket header, 5 pole, pitch 2.5 mm, straight, black, 2439680000
Order No.: 53P1345
EAN: 4050118454758
MPN:
2439680000
BLF 2.50/05/180 SN BK BX
Unit Price (€ / pc.)
3.0940 € *
Available: 0 pcs.
Available in 6 Days: 400 pcs.
Leadtime: On Request **
Female connector, 2439680000, Weidmüller
Printed circuit board connector, closed sideways, 2.50 mm, no. of poles: 5, tin-plated, black, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Anschluss | Federanschluss | |
| Anzahl der Reihen | 1 | |
| Ausführung | Buchsenleiste | |
| Bestückung | bestückt | |
| Farbe | schwarz | |
| Kontaktart | Buchse | |
| Kontaktoberfläche | verzinnt | |
| Nennspannung | 320 V | |
| Nennstrom | 6 A | |
| Orientierung | gerade | |
| Polzahl | 5-polig | |
| Rastermaß | 2.5 mm |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
