1826070000 | Weidmüller

PCB terminal, 4 pole, pitch 5.08 mm, AWG 28-14, 10 A, spring-clamp connection, black, 1826070000

Order No.: 09H1698
EAN: 4032248328789
MPN:
1826070000
LSF-SMT 5.08/04/180 3.5SN BK TU
Series: LSF-SMT
Weidmüller
1826070000 Weidmüller PCB Terminal Blocks Image 1
1826070000 Weidmüller PCB Terminal Blocks Image 2
1826070000 Weidmüller PCB Terminal Blocks Image 3
Image may differ
Unit Price (€ / pc.)
1.7612 € *
Available: 33 pcs.
Available in 6 Days: 140 pcs.
Leadtime: On Request **
Total Price:
1.76 € *
Price list
Quantity
Price per unit*
1 pcs.
1.7612 €
28 pcs.
1.4994 €
112 pcs.
1.3804 €
252 pcs.
1.3328 €
1008 pcs.
1.2257 €
*incl. VAT plus shipping costs
**Subject to prior sale

PCB terminal, 1826070000, WEIDMÜLLER

Printed circuit board terminals, 5.08 mm, number of poles: 4, 180°, Solder pin length: (l): 3.5 mm, black, push-in with actuator, clamping range, max.: 1.5 mm².

Features

  • PCB terminal for fully automatic assembly in reflow soldering
  • With push-in conductor connection system
  • Conductor inserted and slider operated in same direction
Technical specifications
Connection spring-clamp connection
AWG cross-section AWG 28-14
Width 19.44 mm
Colour black
Height 17.5 mm
Contact distance RM 5/5.08
Cable cross-section 0.13-1.5 mm²
Rated voltage 250 V
Rated current 10 A
Pin number 4 pole
Grid 5.08 mm
Depth 7.8 mm
Logistics
Country of origin DE
Customs tariff number 85369010
Original Packaging Bar with 28 pieces
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
