1934250000 | Weidmüller
PCB terminal, 2 pole, pitch 5.08 mm, AWG 26-12, 20 A, screw connection, orange, 1934250000
Order No.: 52P6664
EAN: 4032248590827
MPN:
1934250000
LL 5.08/02/90 3.2SN OR BX
Series: OMNIMATE Signal - Serie LL
Unit Price (€ / pc.)
1.1424 € *
Available: 0 pcs.
Leadtime: 13 Weeks **
Total Price:
1.14 € *
Price list
Quantity
Price per unit*
1 pcs.
1.1424 €
10 pcs.
1.0472 €
50 pcs.
0.9520 €
100 pcs.
0.8568 €
*incl. VAT plus shipping costs
**Subject to prior sale
Print clamp, 1934250000, Weidmüller
PCB terminal, 5.08 mm, no. of poles: 2, 90°, 3.2 mm, orange, clamping yoke connection, 6 mm², box
PCB terminal with application-oriented connection technology for simple and safe transmission of data directly to the PCB.
Technical specifications
| Anschluss | Schraubanschluss | |
| AWG-Leiterquerschnitt | AWG 26-12 | |
| Breite | 10.81 mm | |
| Farbe | orange | |
| Höhe | 20.3 mm | |
| Leiterquerschnitt | 0,08-6,0 mm² | |
| Nennspannung | 300 V | |
| Nennstrom | 20 A | |
| Polzahl | 2-polig | |
| Rastermaß | 5.08 mm | |
| Tiefe | 11 mm |
Download
Logistics
| Ursprungsland | RO |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
