2014050000 | Weidmüller
PCB terminal, 2 pole, pitch 10.16 mm, AWG 22-6, 58 A, screw connection, black, 2014050000
Order No.: 52P9777
EAN: 4050118398724
MPN:
2014050000
LUP 10.16/02/90 5.0SN BK BX
Series: OMNIMATE Power - Serie LUP
Unit Price (€ / pc.)
6.8544 € *
Available: 0 pcs.
Available in 6 Days: 40 pcs.
Leadtime: On Request **
Total Price:
6.85 € *
Price list
Quantity
Price per unit*
1 pcs.
6.8544 €
10 pcs.
6.3784 €
50 pcs.
5.7834 €
*incl. VAT plus shipping costs
**Subject to prior sale
Print clamp, 2014050000, Weidmüller
PCB terminal, 10.16 mm, no. of poles: 2, 90°, 5 mm, black, clamping yoke connection, 16 mm², Box
PCB terminal with application-oriented connection technology for simple and safe transmission of data directly to the PCB.
Technical specifications
| Anschluss | Schraubanschluss | |
| AWG-Leiterquerschnitt | AWG 22-6 | |
| Breite | 21.12 mm | |
| Farbe | schwarz | |
| Höhe | 36.5 mm | |
| Leiterquerschnitt | 0,13-16 mm² | |
| Nennspannung | 300 V | |
| Nennstrom | 58 A | |
| Polzahl | 2-polig | |
| Rastermaß | 10.16 mm | |
| Tiefe | 25.1 mm |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
