WAD 101 + HAP 1 | Weller
1-Channel hot air station, WAD Series, Weller WAD 101 + HAP 1, 105 W, 230 V
Unit Price (€ / pc.)
1,188.81 € *
Available: 0 pcs.
Leadtime: 1 Week **
1-Channel hot air station, WAD 101 + HAP 1, WELLER
WAD 101 hot air station is equipped with digital electronics. This precisely regulates the temperature. The built-in microprocessor circuit automatically recognises all Weller soldering irons and ensures the optimum settings of the connected tool as well as the hot air pencil HAP 1, which comes as standard with the station.
Features
- A wide range of nozzles makes the WAD 101 ideal for many soldering and desoldering applications on surface mount devices (SMD)
- The WAD 101 requires a compressed air supply of oil-free, dry compressed air or nitrogen (N2)
- The ion-free hot air flow of the Pencil HAP 1 is set manually
- The Weller WCB 1 or WCB 2 code boxes can be connected to the WAD 101 for programming additional functions
- A PC interface is only possible with the WCB 2
Technical specifications
| Number of outputs | 1 | |
| Version | hot air station | |
| ESD protection | Yes | |
| Power | 105 W | |
| max. operating temperature | 450 °C | |
| min. operating temperature | 50 °C | |
| Voltage | 230 V | |
| Connector | type F plug |
Download
Logistics
| Country of origin | MX |
| Customs tariff number | 85151100 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
