WD50 33R 1% (F) | WIDAP
Wirewound resistor, 33 Ω, 50 W, ±1 %, WD50 33R 1% (F)
Unit Price (€ / pc.)
3.7842 € *
Available: 0 pcs.
Leadtime: 10 Weeks **
Total Price:
3.78 € *
Price list
Quantity
Price per unit*
1 pcs.
3.7842 €
10 pcs.
3.5105 €
100 pcs.
3.3082 €
500 pcs.
3.1178 €
1000 pcs.
2.9750 €
*incl. VAT plus shipping costs
**Subject to prior sale
Aluminium housed wire-wound resistor, WD50 33R 1% (F), WIDAP
The WD50 33R 1% (F) is a high quality, high stability aluminium housed power resistor designed for direct heat sink attachment. It has a good electrical stability, reliability and is mechanically very rigid.
Features
- Excellent heat transfers and small dimensions
- Custom terminations
- RoHS compliant
Technical specifications
| ohmscher Widerstand | 33 Ω | |
| Ausführung | Hochlast-Drahtwiderstand | |
| Bauform | Chassis | |
| Breite | 30 mm | |
| Höhe | 17 mm | |
| Länge | 50.1 mm | |
| Leistung | 50 W | |
| max. Temperatur | 250 °C | |
| min. Temperatur | -25 °C | |
| Montage | Chassismontage | |
| Nennbelastbarkeit ohne Kühlfläche | 20 W | |
| Toleranz | ±1 % | |
| Temperaturkoeffizient | 60 ppm/K |
Download
Logistics
| Ursprungsland | IN |
| Zolltarifnummer | 85332100 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
