2882S13 | Wiha

Meets your requirements: A variably settable torque covers a large application area.

Simplifies your work : All tools securely arranged in a robust, orderly bag.

Lowers your costs: Electrostatically conductive tools protect electronic components from damage.

Protect your health: With the patented SoftFinish® handle design, ensuring work is kind to hands and muscles. Recommended by doctors and therapists at German Campaign for Healthier Backs.

Increases your efficiency : The correct torque avoids damaging material and no follow-up work is necessary.

Users risk damaging electronic components irreparably when working on them. Such problems become a thing of the past with the TorqueVario®-S ESD torque screwdriver set. The ESD torque screwdriver is manufactured in line with the IEC 61340-5-1 international standard and thus guarantees maximum protection for electronic components. The dissipative tool handle has a surface resistance between 106 and 109 ohm and safely channels electrostatic energy away in a controlled fashion. The torque screwdriver also ensures controlled screw tightening. Thanks to its integrated numeric scale and the supplied adjusting tool, variable torque settings can be made, therefore covering a wide application field. A clearly audible and tactile signal is emitted when triggering the set torque value, guaranteeing process-safe work, protecting material and eliminating follow-up work. With a release accuracy of +/- 6%, the torque tool complies with EN ISO 6789 requirements. The set includes a bit holder for 1/4" bits. The ESD torque screwdriver is also compatible with 4 mm Wiha Torque interchangeable blades (series 2859). All tools in the set are safely stored neatly away in a robust, clearly organised box.

Standards: IEC 61340-5-1.DIN EN ISO 6789.

Application: For controlled fastening at a specific torque on components susceptible to electrostatic discharge.

• 1 x Adjusting tool for torque screwdriver with long handle (26864) 146 mm
• 1 x Bit holder clamping with ball for torque screwdriver with long handle (27526) 1/4 mm, 162 mm
• 1 x Bit Standard 25 mm Phillips 1/4" (01657) PH1
• 1 x Bit Standard 25 mm Phillips 1/4" (05298) PH0
• 1 x Bit Standard 25 mm Pozidriv 1/4" (01688) PZ1
• 1 x Bit Standard 25 mm Pozidriv 1/4" (05300) PZ0
• 1 x Bit Standard 25 mm Slotted 1/4" (01623) 4,5
• 1 x Bit Standard 25 mm Slotted 1/4" (04013) 4,5
• 1 x Bit Standard 25 mm TORX® 1/4" (01713) T7
• 1 x Bit Standard 25 mm TORX® 1/4" (01714) T8
• 1 x Bit Standard 25 mm TORX® 1/4" (01715) T9
• 1 x Bit Standard 25 mm TORX® 1/4" (01716) T10
• 1 x Torque screwdriver TorqueVario®-S ESD Variable torque limit settings (26629) 0,4-1,0 Nm, 4 mm
