MKP2F031001F00KSSD | Wima
MKP film capacitor, 100 nF, ±10 %, 250 V (DC), PP, 5 mm, MKP2F031001F00KSSD
Unit Price (€ / pc.)
0.4879 € *
Available: 3,109 pcs.
Available in 4 Days: 1,972 pcs.
Leadtime: 23 Weeks **
Total Price:
4.88 € *
Price list
Quantity
Price per unit*
1 pcs.
0.7854 €
10 pcs.
0.4879 €
50 pcs.
0.3927 €
250 pcs.
0.3332 €
1000 pcs.
0.2880 €
*incl. VAT plus shipping costs
**Subject to prior sale
Film capacitor, MKP2F031001F00KSSD, WIMA
The MKP2F031001F00KSSD is a metallized capacitor with thin layers of aluminium. The layers are vacuum-deposited on the insulating film as conducting electrodes. In the case of a breakdown, the short circuit current causes the thin metal coating to evaporate around the point of failure and an insulating area is formed. This product is used in the high frequency field. This includes resonant circuits, power supplies, deflection circuits, oscillator circuits and audio equipment.
Features
- High volume/capacitance ratio
- Self-healing
- Very low dissipation factor
- Negative capacitance change versus temperature
- Very low dielectric absorption
Applications
- Sample and hold
- Timing
- Oscillating circuits
- High frequency coupling and decoupling
Technical specifications
| Number of pins | 2 | |
| Design | radial | |
| Width | 5 mm | |
| Dielectric material | PP | |
| Height | 10 mm | |
| Capacity | 100 nF | |
| Length | 7.2 mm | |
| max. operating temperature | 100 °C | |
| min. operating temperature | -55 °C | |
| Rated voltage (AC) | 160 V | |
| Rated voltage (DC) | 250 V | |
| Grid | 5 mm | |
| Tolerance | ±10 % |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85322500 |
| Original Packaging | Bulk with 3,500 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
