860241381004 | Würth Elektronik eiSos
Electrolytic capacitor, 33 µF, 400 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 18 mm, 860241381004
Unit Price (€ / pc.)
3.6176 € *
Available: 98 pcs.
Available in 5 Days: 673 pcs.
Leadtime: 26 Weeks **
Total Price:
3.62 € *
Price list
Quantity
Price per unit*
1 pcs.
3.6176 €
50 pcs.
3.0821 €
100 pcs.
2.6894 €
250 pcs.
2.3919 €
500 pcs.
2.0944 €
*incl. VAT plus shipping costs
**Subject to prior sale
Characteristics
- Capacitance range: 0.2 pF ‒ 350 F
- Capacity tolerance: ±20 %
- Dimensions (DxL) in mm: 5.0 x 11.0 to 18.0 x 35.5
- Lifespan: 5000 ‒ 10000 hours @ +105 °C
- Mounting style: THT Radial
- Operating temperature: -40°C to +105°C for UR ≤100 V(DC), -25°C to +105°C for UR > 100 V(DC)
- Recommended soldering: Wave soldering
- Voltage Range (UR): 10 - 450 V(DC)
- Product series with a long lifespan
- Capacity range: 6.8 µF ‒ 3300 µF
- Mounting type: THT Radial
- Recommended soldering method: Wave soldering
Application:
- Long life applications (industry, medical)
- Filtering
- Smoothing
- Energy storage
- Coupling
- e.g. Switched-mode power supply, AC/DC converter, adapter, charger, digital camera
- Long life applications (industry, medical)
- Filtering
- Smoothing
- Energy storage
- Coupling
- e.g. Switched-mode power supply, AC/DC converter, adapter, charger, digital camera
Technical specifications
| Anschluss | Lötanschluss | |
| Ausführung | Polar | |
| Bauform | radial | |
| Durchmesser | 18 mm | |
| Kapazität | 33 µF | |
| Länge | 21 mm | |
| max. Temperatur | 105 °C | |
| min. Temperatur | -25 °C | |
| Nennspannung (DC) | 400 V | |
| Rastermaß | 7.5 mm | |
| Rippelstrom | 870 mA | |
| Toleranz | ±20 % |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85322200 |
| MSL | MSL 1 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
