686108188822 | Würth Elektronik eiSos

Name: Connector, 8 pole, 1 row, pitch 1 mm, solder connection, tin/nickel plated, 686108188822
Brand: Würth Elektronik eiSos
SKU: 56F8625
Price: 0.98 EUR
Availability: InStock

Connector, 8 pole, 1 row, pitch 1 mm, solder connection, tin/nickel plated, 686108188822

Order No.: 56F8625

EAN: 4099879757074

MPN:

686108188822

Series: WR-FPC 1 mm

Image may differ

Key Specification:

Polzahl 8-polig

Anzahl der Reihen 1

Rastermaß 1 mm

Anschluss Lötanschluss

Show 15 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.9758 € *

Available: 50 pcs.

Available in 5 Days: 10,000 pcs.

Leadtime: 11 Weeks **

Total Price:

0.98 € *

Price list

Quantity

Price per unit*

1 pcs.

0.9758 €

25 pcs.

0.8806 €

100 pcs.

0.8211 €

250 pcs.

0.7616 €

500 pcs.

0.7140 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Technical specifications

Show similar products 0

Download

Technisches Datenblatt - EN Technisches Datenblatt

Konformitätsdeklaration - EN Konformitätsdeklaration

Konformitätsdeklaration - DE Konformitätsdeklaration

Logistics

Ursprungsland	CN
Zolltarifnummer	85366930
MSL	MSL 1
Originalverpackung	Rolle mit 950 Stück

Compliance

RoHS konform	Yes
Stand der RoHS-Richtlinie	3/31/15
SVHC frei	Yes
