2513130810201 | Würth Elektronik eiSos
Differential pressure sensors, -10 to 10 kPa / 0 to 70°C, 4.75-5.25 V, 2513130810201, SMD-8, -25 to 85 °C, 2513130810201
Unit Price (€ / pc.)
41.1145 € *
Available: 50 pcs.
Available in 5 Days: 5,088 pcs.
Leadtime: 16 Weeks **
Total Price:
41.11 € *
Price list
Quantity
Price per unit*
1 pcs.
41.1145 €
10 pcs.
40.1863 €
50 pcs.
36.7115 €
*incl. VAT plus shipping costs
**Subject to prior sale
Characteristics
- I²C, UART and SPI digital communication interface
- Different transfer functions from ±0.1 kPa to 1500 kPa
- Integrated temperature sensor
- Fully calibrated 15 bit digital & 11 bit analog pressure output
- Individualization
- MEMS based piezo-resistive sensing principle
- Operating supply voltage 3.3 V is available
- Temperature range: -25 °C to 85 °C
- Very high accuracy (up to ±0.25 % FSS tolerance)
Application:
- HVAC
- Filter monitoring
- Gas leak detection
- Inhalers
- Fume hood
Technical specifications
| Ausführung | Differentialdruck-Sensor | |
| Gehäuse | SMD-8 | |
| max. Temperatur | 85 °C | |
| Messbereich | -10 bis 10 kPa / 0 bis 70°C | |
| min. Temperatur | -25 °C | |
| Montage | SMD | |
| Spannung | 4,75-5,25 V |
Download
Logistics
| Ursprungsland | SI |
| Zolltarifnummer | 85423911 |
| MSL | MSL 1 |
| Originalverpackung | Rolle mit 500 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
