D459-B8AA | ZF Switches and Sensors
Miniature snap-action switche, On-On, solder connection, pin plunger, 1 N, 16 (4) A/250 VAC, 10 (3) A/400 VAC, IP40, D459-B8AA
Unit Price (€ / pc.)
1.3209 € *
Available: 47 pcs.
Leadtime: On Request **
Total Price:
33.02 € *
Price list
Quantity
Price per unit*
25 pcs.
1.3209 €
100 pcs.
1.2138 €
250 pcs.
1.1543 €
*incl. VAT plus shipping costs
**Subject to prior sale
Miniature snap-action switches, type Cherry D459.
Switching function: CO. Breaking power: 16 (4) A/250 VAC, 10 (3) 400 VAC (EN 61058), 15 A 125/250 VAC (UL 1054). Contacts: AgNi. Leakage current resistance: PTI 300. Operating temperatures: –40 to + +85 °C. Terminals: CuZn. Electrical useful life: 50,000 switching cycles. Certifications: ENEC, UL, CSA.
Without auxiliary actuator.
Switch actuating force: 100 cN. Action point: 14.7 mm (±0.5). Pretravel: maximum 1.2 mm. Overtravel: minimum 1.3 mm. Travel difference: maximum 0.3 mm. Home position: maximum 16.2 mm.
Technical attributes (type, termination): D459-B8AA, solder connections
Technical specifications
| Connection | solder connection | |
| Design | angled | |
| Actuator | pin plunger | |
| actuating force | 1 N | |
| Shell Material | PET | |
| Latching switching function | On-On | |
| Breaking capacity | 16 (4) A/250 VAC, 10 (3) A/400 VAC | |
| Switching point | 14.7 mm ±0.5 mm | |
| Protection class | IP40 |
Download
Logistics
| Country of origin | UA |
| Customs tariff number | 85365080 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
