BYB-5-91F619 | by.B

Silicone-switching strand, halogen free, SiF, 0.5 mm², green/yellow, outer Ø 2.1 mm, BYB-5-91F619

Order No.: 91F619
EAN: 4099891170615
MPN:
BYB-5-91F619
SIF 0,50/2,1 GN/GE
Series: SiF
by.B
BYB-5-91F619 by.B Insulated stranded wires
Image may differ
Print
Key Specification:
Cable cross-section 0,5 mm²
Cable structure 16 x 0,2 mm
Colour grün/gelb
Core insulation material Silikon

Ordering Information:

not to be sold to private customers
Show 37 variants
Download Datasheet Technical specifications
Unit Price (€ / mtr.)
0.6188 € *
Available: 355 mtr.
Next delivery: 200 mtr. on 2025-05-21
Leadtime: 12 Weeks **
Total Price:
0.62 € *
Price list
Quantity
Price per unit*
1 mtr.
0.6188 €
10 mtr.
0.4998 €
100 mtr.
0.4284 €
500 mtr.
0.3808 €
1000 mtr.
0.3332 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

Stranded hook-up wires with silicon insulation, type SiF.

Tinned copper, silicon insulation

Cross-section 0.5 mm², outer diameter 2.1 mm,.
Technical specifications
Core insulation material Silikon
Outer diameter 2.1 mm
Colour grün/gelb
Halogen free Yes
Cable structure 16 x 0,2 mm
Cable material Kupfer, verzinnt
Cable cross-section 0,5 mm²
Rated voltage 300 V
Test voltage 2 kV
Temperature range (active) bis 180 °C
Show similar products 0
Logistics
Country of origin IT
Customs tariff number 85444995
Original Packaging Ring mit 100 Meter
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
