4312.0003 | SCHURTER
Appliance inlet S15, 3 pole, cable assembly, screw connection, 1.5 mm², black, 4312.0003
Unit Price (€ / pc.)
28.1078 € *
Available: 0 pcs.
Leadtime: 11 Weeks **
Total Price:
28.11 € *
Price list
Quantity
Price per unit*
1 pcs.
28.1078 €
10 pcs.
26.1324 €
25 pcs.
24.3117 €
50 pcs.
22.1221 €
*incl. VAT plus shipping costs
**Subject to prior sale
Device socket, 4312.0003, SCHURTER
IEC Device socket protection degree IP67/IP69K, Rewireable, Straight.
Features
- Cord connector rewireable
- Complete set consisting of appliance inlet and outlet
- Housing material: Thermoplastic, UL 94V-0
- Protection class: 1
Technical specifications
| Anschluss | Schraubanschluss | |
| Ausführung | Kupplung | |
| Bauform | gerade | |
| Farbe | schwarz | |
| IEC-Bezeichnung | S15 | |
| Kabeldurchmesser | 10 mm | |
| Leiterquerschnitt | 1,5 mm² | |
| Montage | Kabelmontage | |
| Nennspannung IEC | 250 V | |
| Nennspannung UL/CSA | 250 V | |
| Nennstrom IEC | 10 A | |
| Nennstrom UL/CSA | 15 A | |
| Netzfilter vorhanden | No | |
| Netzschalter beleuchtet | No | |
| Netzschalter vorhanden | No | |
| Polzahl | 3-polig | |
| Sicherungshalter vorhanden | No | |
| Stifttemperatur | 120 °C |
Download
Logistics
| Ursprungsland | CH |
| Zolltarifnummer | 85366990 |
| MSL | MSL 1 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
