3405.0174.24 | SCHURTER
SMD-Fuse 3 x 10.1 mm, 6.3 A, F, 125 V (DC), 250 V (AC), 200 A breaking capacity, 3405.0174.24
Unit Price (€ / pc.)
0.5117 € *
Available: 0 pcs.
Leadtime: 9 Weeks **
SMD-Fuse, 3405.0174.24, SCHURTER
The 3405.0174.24 is a quick-acting fuse designed to protect less sensitive components and are also used to protect cabling from melting or catching fire when an overload occurs.
Features
- Material glass tube
- Material terminals copper alloy gold-plated
- Directly solderable on printed circuit boards
- UMF (universal modular fuse)
Applications
- Primary protection on SMD PCB-s
- Medical equipment
- Power supplies
- Illumination
Technical specifications
| Ausführung | SMD-Sicherung | |
| Auslösecharakteristik | F | |
| Ausschaltvermögen | 200 A | |
| Bauform | 3 x 10,1 mm | |
| Breite | 3 mm | |
| Gehäuse | SMD | |
| Höhe | 3 mm | |
| Länge | 10.1 mm | |
| Nennspannung (AC) | 250 V | |
| Nennspannung (DC) | 125 V | |
| Nennstrom | 6.3 A |
Download
Logistics
| Ursprungsland | CH |
| Zolltarifnummer | 85361010 |
| MSL | MSL 1 |
| Originalverpackung | Blister mit 2.000 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
