62.7436-91021 | Stäubli Electrical Connectors
Polyolefine-photovoltaic cable, halogen free, Cableline, 6.0 mm², black, outer Ø 6.97 mm, 62.7436-91021
Unit Price (€ / mtr.)
1.9040 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Total Price:
1.90 € *
Price list
Quantity
Price per unit*
1 mtr.
1.9040 €
10 mtr.
1.7612 €
50 mtr.
1.6184 €
100 mtr.
1.5232 €
500 mtr.
1.4280 €
*incl. VAT plus shipping costs
**Subject to prior sale
PV cable, 62.7436-91021, Stäubli Electrical Connectors
Halogen free cross-linked polyolefin double layers photovoltaic cables for use at the photovoltaic power systems.
Technical specifications
| Core insulation material | Polyolefin | |
| Outer diameter | 6.97 mm | |
| Colour | schwarz | |
| Halogen free | Yes | |
| Cable structure | 78 x 0,3 mm | |
| Conductor category | Kl.5 = feindrähtig | |
| Cable material | Kupfer, verzinnt | |
| Cable cross-section | 6,0 mm² | |
| Rated voltage | 1.5 kV | |
| Rated voltage UL/CSA | 2 kV | |
| Standard number | UL | |
| Test voltage | 15 kV | |
| Temperature range (active) | -40 °C bis 90 °C |
Download
Logistics
| Customs tariff number | 85444999 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
