B41456B8339M000 | TDK (EPCOS)
Electrolytic capacitor, 33000 µF, 63 V (DC), ±20 %, can, pitch 22.2 mm, Ø 51.6 mm, B41456B8339M000
Nicht geeignet für Neudesigns
Unit Price (€ / pc.)
29.2026 € *
Available: 0 pcs.
Leadtime: On Request **
Electrolytic capacitor, B41456B8339M000, EPCOS
Aluminum electrolytic capacitor - Screw terminal capacitor
Features
- High ripple current capability
- Long useful life
- High reliability
- All-welded construction ensures reliable electrical contact
Applications
- General industrial electronics
- For switch-mode power supplies in professional equipment
Technical specifications
| Anschluss | Schraubanschluss | |
| Ausführung | Polar | |
| Bauform | Becher | |
| Durchmesser | 51.6 mm | |
| ESR (Äquivalenter Serienwiderstand) | 6 mΩ | |
| Kapazität | 33000 µF | |
| Länge | 105.7 mm | |
| max. Temperatur | 85 °C | |
| min. Temperatur | -40 °C | |
| Nennspannung (DC) | 63 V | |
| Rastermaß | 22.2 mm | |
| Rippelstrom | 14 A | |
| Toleranz | ±20 % |
Download
Logistics
| Ursprungsland | HU |
| Zolltarifnummer | 85322200 |
| Originalverpackung | Karton mit 36 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
