THD 15-2411N | TRACO POWER
DC converter, 18-36 VDC, 15 W, 1 output, 5.1 VDC, 90 % efficiency, THD 15-2411N
Unit Price (€ / pc.)
47.9451 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Total Price:
47.95 € *
Price list
Quantity
Price per unit*
1 pcs.
47.9451 €
10 pcs.
43.1375 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC Converter, THD 15-2411N, TRACO POWER
The THD 15-2411N provides 15 W output power out of a very compact shielded metal case that occupies only 1 inch² of board space. The converter works with a high efficiency over the full load range and draws a very low input current at no load conditions. It has a wide 2:1 input voltage range and a precisely regulated output voltage.
Features
- Industry standard pinout
- Remote On/Off control
Technical specifications
| Anzahl der Ausgänge | 1 | |
| Ausgangsspannungsbereich | 5,1 VDC | |
| Ausgangsstrom | 3 A | |
| Bauform | DIP24 | |
| Breite | 20.3 mm | |
| Eingangsspannungsbereich | 18-36 VDC | |
| Höhe | 10.2 mm | |
| Isolationsspannung | 1.6 kV | |
| Länge | 31.8 mm | |
| Leistung | 15 W | |
| Wirkungsgrad | 90 % |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
