DC converter, 18-75 VDC, 15 W, 1 output, 24 VDC, 91 % efficiency, THL 15-4815WI
DC/DC converters, Traco THL 15-4815WI
The THL 15WI series is Traco Power’s latest addition to the existing 15 Watt DC/DC converter range. With the focus on combining cost efficiency and quality this isolated high performance 15 Watt DC/DC converter is suitable for many different applications. The series comes in an encapsulated, shielded 1” x 1” x 0.4” metal package and has a fully integrated EN 55032 class A filter. High efficiency up to 91% enables the converter to operate from –40°C to +70°C without derating. All models have an ultra wide 4:1 input voltage range and precisely regulated, isolated outputs. The series meets the latest IT safety certifications (UL 62368-1) and is thus eligible for uses in mobile equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where cost efficiency and quality are critical factors.
| Anzahl der Ausgänge | 1 | |
| Ausgangsstrom | 625 mA | |
| Ausgangsspannungsbereich | 24 VDC | |
| Eingangsspannungsbereich | 18-75 VDC | |
| Leistung | 15 W | |
| Wirkungsgrad | 91 % | |
| Bauform | DIP6 | |
| Isolationsspannung | 1.8 kV | |
| Länge | 25.4 mm | |
| Breite | 25.4 mm | |
| Höhe | 10.2 mm |
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
