TSR 1-2425SM | TRACO POWER
DC converter, 4.6-36 VDC, 3 W, 1 output, 2.5 VDC, 87 % efficiency, TSR 1-2425SM
Unit Price (€ / pc.)
10.9480 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Total Price:
10.95 € *
Price list
Quantity
Price per unit*
1 pcs.
10.9480 €
10 pcs.
9.8413 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TSR 1-2425SM
The TSR-1SM series models of step-down switching regulators have a high efficiency up to 96 % which allows full load operation up to +65°C ambient temperature without the need of any heat transmission layer. Excellent output voltage accuracy (±2%) and low standby current (~1 A) are features that distinguish these switching regulators from linear regulators.
Technical specifications
| Anzahl der Ausgänge | 1 | |
| Ausgangsspannungsbereich | 2,5 VDC | |
| Ausgangsstrom | 1 A | |
| Bauform | SMD | |
| Breite | 9.3 mm | |
| Eingangsspannungsbereich | 4,6-36 VDC | |
| Höhe | 7.6 mm | |
| Länge | 15.2 mm | |
| Leistung | 3 W | |
| Wirkungsgrad | 87 % |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
