1767670000 | Weidmüller
Protective conductor terminal, spring balancer connection, 1.5-10 mm², 3 pole, 1200 A, 8 kV, yellow/green, 1767670000
Unit Price (€ / pc.)
9.2939 € *
Available: 17 pcs.
Available in 6 Days: 100 pcs.
Leadtime: On Request **
Total Price:
9.29 € *
Price list
Quantity
Price per unit*
1 pcs.
9.2939 €
10 pcs.
8.6513 €
50 pcs.
7.8659 €
*incl. VAT plus shipping costs
**Subject to prior sale
Protective conductor terminal block, 1767670000, Weidmüller
Protective conductor terminal block, spring-cage connection, 10 mm², 800 V, number of connections: 3, number of levels: 1, green / yellow.
Clamp with protective conductor contact for connecting or joining wires, cores and cables with permanently safe contact. Hardened steel for the mechanical forces and high-quality copper with tin coating ensure the best conductivity.
Technical specifications
| Version | Schutzleiter-Reihenklemme | |
| Number of terminals | 2 | |
| Pin number | 3-polig | |
| Cable cross-section | 1,5-10 mm² | |
| AWG cross-section | AWG 16 bis 6 | |
| Rated surge voltage | 8 kV | |
| Rated current | 1200 A | |
| Rated Voltage | 800 V | |
| Degree of soiling | 3 | |
| Length | 99 mm | |
| Width | 10.1 mm | |
| Height | 49.5 mm | |
| Connection | Federzuganschluss | |
| Colour | gelb/grün |
Download
Logistics
| Country of origin | RO |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
